Powerful pump built with durable materials in an easy handling design. Top discharge provides maximum motor cooling efficiency allowing continuous duty operation at low levels and extended dry-run capability.

Features

• LB-480 slimline design pump allows to fit into 8" pipes
• Urethane, semi vortex impeller and wear plates for maximum durability and maintaining pump performance
• Dual inside mechanical seal with SiC faces provides longer operational life
• Oil lifter provides lubrication of the seal faces. (Patented)
• V-Ring seal design protects mechanical seal from abrasive particles (Optional Accessories)
• TS-301 Float Switch for automatic operation

Specification

• Brand: Tsurumi Pump
• Product Type: Submersible Pump
• Motor Output: 2/3 HP
• Phase: Single
• Discharge Bore: 2"
• Max Solid Diameter: 0.236"
• Voltage/Amp: 110/6.1
• Cable Length: 32'
• Diameter: 7-11/16"
• Height: 11-1/4"
• Continuous Running Water Level: 2"
• Pump Weight: 28 lbs
